HAYNES 230
UNS N06230
產品介紹:
化學成分:
承懷特種 合金 | % | Ni | Cr | W | Mo | Co | Fe | Mn | Si | C | Al | P | S | La | B |
UNS N06230 | 最小 | 余量 | 20 | 13 | 1 | - | - | 0.3 | 0.25 | 0.05 | 0.2 | - | - | 0.005 | - |
最小 | 余量 | 24 | 15 | 3 | 5 | 3 | 1 | 0.75 | 0.15 | 0.50 | 0.03 | 0.015 | 0.05 | 0.015 |
產品形式及執行標準:
產品 | ASME標準 | ASTM標準 | AME標準 |
板材、薄板、帶材 | SB435 | B435 | 5878 |
棒材 | SB572 | B572 | 5891 |
鍛材 | SB564 | B564 | 5891 |
焊接公稱管 | SB619 | B619 | - |
無縫公稱管和管子 | SB622 | B622 | - |
焊接管子 | SB626 | B626 | - |
鍛造連接件 | SB366 | B366 | - |
物理性能:
密度 | 8.97G/CM3 |
熔點 | 1301-1371℃ |
產品特性:
HAYNES 230綜合了多數高溫合金的強度、穩定性、抗氧化性、熱循環抗力、可加工性、在持續高溫下的抗晶粒粗化的特性和相對低的熱膨脹特性。
應用鄰域:
燃氣輪機的燃燒器及其他關鍵非運動部件
熱處理和工業加熱
化工
石油工業
熱電廠
公司主要生產加工以下產品:
1.變形高溫合金:GH1015, GH1016, GH1035, GH1040, GH1131, GH1140, GH2018, GH2036, GH2038, GH2130, GH2132, GH2135, GH2136, GH2302, GH3030, GH3039, GH3044, GH3128, GH4033, GH4037, GH4043, GH4049, GH4133, GH4169.
2.哈氏合金:Hastelloy B, Hastelloy B-2, Hastelloy B-3, Hastelloy C, Hastelloy C-4, Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000, Hastelloy G-30, Hastelloy G-35, Hastelloy N, Hastelloy S, Hastelloy W, Hastelloy X.
3.英科耐爾合金:Inconel 600, Inconel 601, Inconel 601GC, Inconel 617, Inconel 622, Inconel 625, Inconel 625LCF, Inconel 671, Inconel 672, Inconel 686, Inconel 690, Inconel 706, Inconel 718, Inconel 718SPF, Inconel 725, Inconel X-750, Inconel 751, Inconel 754, Inconel 758, Inconel 783.
4.因科洛伊合金:Incoloy DS, Incoloy 800, Incoloy 800H, Incoloy 802, Incoloy 803, Incoloy 804, Incoloy 825, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy MA956, Incoloy A-286, Incoloy 25-6Mo.
5.蒙乃爾合金:Monel 400, Monel R-405, Monel 450, Monel K-500, Monel S.
6.耐蝕合金:NS111, NS112, NS142, NS143, NS312, NS313, NS315, NS321, NS322, NS333, NS334, NS335, NS336.
7.鐵鎳合金/軟磁合金
1j22 1j30 1j34 1j50 1j66 1j79 1j80 1j85 4j29 4j33 4j36 4j42 4j50
